- Product Specs
-
Additional Information
Manufacturer CISCO Manufacturer Part Number CISCO1760 SKU GROUP-127541 Ethernet Technology Fast Ethernet Flash Memory 32 MB Marketing Information The Cisco 1760 Modular Access Router offers small and medium-sized businesses and enterprise small branch offices a 19-inch rack-mount access solution designed to enable them to grow their e-business capabilities. The base version Cisco 1760 router, address the needs of customers who want to deploy e-business applications now or in the future. The Cisco 1760 router, as a modular platform in a 19-inch rack-mount form factor, offers customers secure Internet and intranet access, as well as the capability to implement a variety of e-business and voice applications. This includes voice over IP (VoIP), virtual private network (VPN) access, and business-class digital subscriber line (DSL) as required. The Cisco 1760 router is part of a broad portfolio of access routers optimized to deliver intelligent services such as quality of service (QoS), manageability, availability, and security. The base version Cisco 1760 router, address the needs of customers who want to deploy transformation technologies such as converged voice and data, IP telephony, or videoconferencing. Description The Cisco 1760 Modular Access Router offers small and medium-sized businesses and enterprise small branch offices a 19-inch rack-mount access solution designed to enable them to grow their e-business capabilities. The base version Cisco 1760 router, address the needs of customers who want to deploy e-business applications now or in the future. Depth 11.5" Brand Cisco Certifications & Standards - Regulatory Approvals (Safety, EMC, and Telecom Compliance)
- Safety
- UL 60950, 3rd Edition (includes Czech Republic)- - CSA 22.2 No 60950, 3rd Edition
- - EN60950, 3rd Edition
- - TS001-1997
- - AS/NZS 3260 with A1 through A4
- - IEC 60950, 3rd Edition and all country deviations
- - ETSI 300-047 GOST-R
- EMC
- - EN55022 (CISPR22) Class A
- - EN55022/EN50082
- - CFR47 part 15 Class A
- - ICES 003, issue 2 Class A
- - VCCI Class A
- - AS/NZS 3548: Class A
- - EN55024 (CISPR24) Immunity:
- - EN61000-4-2 ESD
- - EN61000-4-3 Radiated immunity
- - EN61000-4-4 Electrical fast transients
- - EN61000-4-5 Surge
- - EN61000-4-6 Conducted RF immunity
- - EN61000-4-11 AC dips and sags
- - EN61000-3-2 AC harmonics and flicker
- GOST-R
- Telecom
- Europe: CTR2, CTR3, TBR21
- Canada: CS-03 Part I, II, VI, VIII
- United States: TIA-IS-968
- Japan: JATE
- Australia/New Zealand: TS002, TS003, TS006, S.043, TS031
- Brazil: Anatel
- China: GB-514-92, YD-514-92; Hong Kong: HKTA 2011, 2014, 2015, 2017
- Hungary ETR328 (T)
- Mexico: CFT
- Singapore: IDA
- Poland PB-TE rev. 2 (T)
- South Africa: ICASA
- South Korea: MIC
- IEEE 802.3-LAN
- IEEE 802.3U-LAN
- IEEE 802.1Q
Expansion Slot Type VIC/WIC VIC Form Factor - Rack-mountable
- Wall Mountable
Product Name CISCO1760 Input Voltage - 110 V AC
- 220 V AC
Maximum Memory 128 MB Memory Technology DRAM Alt Part No CISCO1760 Network Technology 10/100Base-TX Product Type Router Number of Network (RJ-45) Ports 1 Number of Total Expansion Slots 5 Additional Information RJ-45 jack with EIA/TIA-232 interface (plug compatible with Cisco 2500 Series AUX port); asynchronous serial DTE with full modem controls (CD, DSR, RTS, CTS); asynchronous serial data rates up to 115.2 kbps RJ-45 jack with EIA/TIA-232 interface (plug compatible with Cisco 1600 and 2500 Series console ports); asynchronous serial DTE; transmit/receive rates up to 115.2 kbps (default 9600 bps, not a network data port); note: no hardware handshaking such as RTS/CTS One internal expansion slot: Supports hardware-assisted services such as encryption (up to T1/E1) NSN Part Number 5.90E+12 SKU UNSPSC 43222609 SKU UPC 7.46E+11 Standard Memory 64 MB Total Number of Ports 1 - Description
-
Details
The Cisco 1760 Modular Access Router offers small and medium-sized businesses and enterprise small branch offices a 19-inch rack-mount access solution designed to enable them to grow their e-business capabilities. The base version Cisco 1760 router, address the needs of customers who want to deploy e-business applications now or in the future. - Reviews
-
