Manufacturer CISCO Manufacturer Part Number WS-C6509 SKU GROUP-212546 Marketing Information The 9-slot Cisco Catalyst 6509 offers scalable port densities, ideal for many wiring-closet, core and data-center deployments. When equipped with a single Catalyst 6500 Series supervisor engine, eight payload slots are available to support a wide range of interface or services modules. Redundant supervisor engine configurations using fast 13 second failover are also supported for maximum network uptime. The Catalyst 6509 offers a range of power supply options, including redundant power supplies ranging from 1000W AC or DC to 4000W AC. The Catalyst 6509 also features field upgradable fan trays for easy service. Description The 9-slot Cisco Catalyst 6509 offers scalable port densities, ideal for many wiring-closet, core and data-center deployments. When equipped with a single Catalyst 6500 Series supervisor engine, eight payload slots are available to support a wide range of interface or services modules. Redundant supervisor engine configurations using fast 13 second failover are also supported for maximum network uptime. Series Cisco Catalyst 6500 Height 25.5" Width 17.3" Depth 18.4" Brand Cisco Certifications & Standards - Safety:
- UL 1950
- EN 60950
- CSA-C22.2 no. 950
- IEC 60950
- AS/NZA 3260
- 21 CFR 1040
- EN 60825-1
- IEC 60825-1
- TS 001
- EMC:
- FCC (CFR 47, Part 15) Class A
- VCCI
- CE Marking
- EN 55022
- EN 55024
- CISPR 22
- AS/NZS 3548
- NEBS Level 3 (GR-1089-CORE, GR-63-CORE)
- ETSI ETS-300386-2 IEEE Compliance:
- 802.1d Bridging
- 802.1p, q VLAN tagging
- 802.1s Per-VLAN Group Spanning Tree Protocol
- 802.1w Rapid Spanning Tree Protocol
- 802.1x
- 802.3 10BASE-T, 10BASE-FL
- 802.3ad Link aggregation
- 802.3ab 1000BASE-T
- 802.3ae 10 Gigabit Ethernet
- 802.3u 100BASE-TX, 100BASE-FX
- 802.3x Flow control
- 802.3z 1000BASE-SX, 1000BASE-LX
- RFC Compliance:
- ATM:
- - 1483, 2584
- BGP4:
- - 1269 , 1745 , 1771 , 1965 , 1966 , 1997, 2385, 2439, 2796, 2842
- General routing protocols:
- - 768, 783, 791, 792, 793, 826, 854, 894, 903, 906, 951, 1542, 1027, 1122, 1256, 1519, 1541, 1591, 1619, 1662, 1812, 2131, 2338
- IP multicast:
- - 1112, 1122, 2236, 2283, 2362
- Intermediate system to Intermediate system (IS-IS):
- - 1195, 1377, 2763, 2966
- LSP tunnels:
- - 2211, 2702
- MPLS:
- - 2547, 2961, 3031, 3032, 3036,
- OSPF:
- - 1583, 1587, 1745, 1765, 1850, 1997, 2154, 2178, 2328, 2370, 2385, 2439, 2842, 2918
- RIP:
- - 1058, 1723, 2453
- Miscellaneous protocols:
- - 1866, 2030, 2068
- Denial of service (DoS) protection:
- - 2267
- Network management:
- - 782, 783, 854, 951, 1155, 1156, 1157, 1212, 1213, 1215, 1256, 1285, 1354, 1493, 1516, 1573, 1643, 1650, 1657, 1724, 1757, 1850, 1901, 1907, 1908, 2021, 2037, 2096, 2233, 2613, 2668, 2787, 2925, 1492, 2138, 2668, 2787, 2925
- Security:
- - 1492, 2138
Product Name CISCO WS-C6509 Input Voltage - 110 V AC
- 220 V AC
Limited Warranty 90 Day Manageable Yes Alt Part No WSC6509 MTBF 61361 Hour Product Type Ethernet Switch Number of Total Expansion Slots 9 Additional Information - Item Included:
- Catalyst 6000 Blank Line Card Slot Cover (WS-X6K-SLOT-CVR)
- PKG,PWR SPLY INSERT,CAT 5500 (5500-PS-INSERT)
- Supports all Catalyst 6500 modules, including all:
- Supervisor engines:
- - Supervisor 1, 2, 720
- Switch fabric modules
- Fast Ethernet modules
- Gigabit Ethernet modules
- 10 Gigabit Ethernet modules
- Voice modules
- Flex Wan Modules
- ATM modules
- Multi Gigabit services modules (content services ,firewall, intrusion detection, IPSec/VPN, network analysis, and SSL acceleration)
- Airflow: 200 lfm through system fan assembly
- Noise levels: 49.8 to 53.6 dBa
- Weight (Chassis fully configured with 1 supervisor engine, 8 switching modules, and 2 power supplies): 135 lb (61.2 kg)
- Chassis depth including cable guide is 21.64 in. (55.0 cm)
- Provides maximum uptime with redundancy and rapid 2-3 second failover across supervisor engine
Power Source Power Supply Product Line Catalyst Redundant Power Supply Yes NSN Part Number 5.98E+12 SKU UNSPSC 43222612 SKU UPC 7.46E+11 - Description
-
Details
The 9-slot Cisco Catalyst 6509 offers scalable port densities, ideal for many wiring-closet, core and data-center deployments. When equipped with a single Catalyst 6500 Series supervisor engine, eight payload slots are available to support a wide range of interface or services modules. Redundant supervisor engine configurations using fast 13 second failover are also supported for maximum network uptime. - Reviews
-
