- Product Specs
-
Additional Information
Manufacturer CISCO Manufacturer Part Number AIR-LAP1131AG-E-K9 SKU GROUP-114684 Ethernet Technology Fast Ethernet Marketing Information Cisco Aironet 1130AG IEEE 802.11a/b/g Lightweight Access Point provide high-capacity, high-security, enterprise-class features in an unobtrusive, office-class design, delivering WLAN access with the lowest total cost of ownership. Two high-performing radios provide simultaneous support for 802.11a and 802.11g standards, delivering 108 Mbps data rates in the 5 and 2.4 GHz bands to distances surpassing that of previous-generation radios. For smooth migration, the Cisco Aironet 1130AG IEEE 802.11a/b/g Lightweight Access Point takes full advantage of the dual-band capabilities of today's WLAN clients, while providing full backward compatibility for legacy 802.11b clients. Description 108Mbps Series 1130 Access Point Height 7.5" Depth 1.3" Antenna Gain - 3 dBi
- 4.5 dBi
Antenna Type Omnidirectional Antenna Brand Cisco Certifications & Standards - Wi-fi
- UL 60950-1
- CAN/CSA-C22.2 No. 60950-1
- UL 2043
- IEC 60950-1
- EN 60950-1
- NIST FIPS
- RSS-210 (Canada)
- RSS-102
- EMI and susceptibility (Class B)
- ICES-003 (Canada)
- WPA2
- WPA
- IEEE 802.1X
- IEEE 802.11i
- IEEE 802.11a
- IEEE 802.11b
- IEEE 802.11g
- FCC Part 15.107 and 15.109
- FCC Bulletin OET-65C
- FCC Part 15.247, 15.407
- FCC Part 15.247, 15.407
Product Name Aironet 1130AG Wireless Access Point Indoor Antenna Range 450 ft ISM Band Yes ISM Minimum Frequency 2.41 GHz Limited Warranty 1 Year Management - BootP
- Secure Shell (SSH) Protocol
- Secure HTTP (HTTPS)
- Trivial File Transfer Protocol (TFTP)
- FTP
- Telnet
- Console port
- Simple Network Management Protocol (SNMP) MIB I and MIB II
- CiscoWorks Resource Manager Essentials (RME)
- CiscoWorks Software Image Manager (SWIM)
- CiscoWorks Campus Manager
- CiscoWorks CiscoView
- CiscoWorks WLSE
Alt Part No AIRLAP1131AGEK9 Product Type Wireless Access Point Number of Network (RJ-45) Ports 1 Outdoor Antenna Range 950 ft Additional Information Interface: 1 x 10/100 BASE-T Ethernet Product Line Aironet SKU UNSPSC 43222631 SKU UPC 8.83E+11 UNII Minimum Frequency 5.15 GHz UNII Maximum Frequency 5 GHz UNII Band Yes Wireless LAN Standard IEEE 802.11a/b/g Wireless Security - WPA
- WPA2 (802.11i)
- IEEE 802.11 WEP
- 802.1X EAP
Wireless Transmission Speed 108 Mbit/s - Description
-
Details
108Mbps - Reviews
-
